Panel mount monitor a 40 inch 1920 x 1080 full HD wide screen industrial LCD display with VGA + DVI-D + HDMI + BNC + S-Video + audio + remote controller video input and open frame metal construction. Option for TV (NTSC / PAL), MCS OSD control & 24 / 48VDC power supply.
Loading...
21.5

PMW6220

17

PMH8170

PMW6440

  • Open frame metal construction
  • 2.8 inchshort depth casing
  • 40 inch 1920 x 1080 full HD wide screen industrial monitor
  • VGA + DVI-D + HDMI + BNC + S-Video video input
  • Audio input with remote controller
  • Option for TV (NTSC / PAL)
  • Option for MCS OSD control
  • Wall / panel / VESA (M6) mount ready
  • 110/220 auto-switch AC power adapter
  • option for 24 /48VDC power supply
$1,545.00
Availability: In stock
SKU
PMW6440
Email
Panel mount monitor - 40 inch 1920 x 1080 wide screen LED back light industrial LCD, VGA + DVI-D + HDMI + BNC + S-Video + audio + remote controller video input & open frame metal construction. Option for TV (NTSC / PAL), MCS OSD control & 24 / 48VDC power supply.
Material
Heavy duty steel
LCD Panel
Size: 40 inch, widescreen
Max Resolution: 1920 x 1080
Brightness (cd/m²): 400
Contrast Ratio (typ): 4000:1
Viewing Angle (H/V): 178° x 178°
Active Area (mm): 886 x 498
Colors: 16.7M
Backlight: LED
MTBF (hrs): 30,000
Video input
VGA + DVI-D + HDMI + BNC + S-Video + Audio + remote controller
OSD menu control
OSD membrane switch control for
Brightness, Contrast, Phase & Clock, Color, H & V position, Auto-tune
Option for MCS multi-display OSD menu control
1 x RS-232 link port & x 2 RJ-45 ports in/out ports
Cascade up to 64 monitors
RS-232 (link to computer) port
RJ 45 port ( in/out ports between each monitor)
(Cat5 or Cat6 cable, up to 300 meters between each monitor)
TV Tuner (Option)
TV tuner (NTSC / PAL) with analog single input
Rear Panel Control
Power on/off switch
OSD membrane switch
Mounting Type
Open frame panel mount or VESA (M6, 8pcs) mount
Power Supply
Auto-sensing 100 to 240VAC, 50/ 60Hz power adapter
Consumption: Max. 200 Watt, Standby 20 Watt
Option for 24V / 48V DC power supply
Weight
100 lb / 45.4 kg
Dimension
38.8"(W) x 23.6"(H) x 2.8"(D)
Environmental
Operating Temperature: 0°C to 50°C
Storage Temperature: -5°C to 60°C
Relative Humidity: 5~90%, non-condensing
Shock: 10G acceleration (11 ms duration)
Vibration: 5~500Hz 1G RMS random vibration
Certification
FCC, CE

PMW6440:
40 inch 1920 x 1080 400-nit high brightness widescreen industrial LCD display, VGA + DVI + HDMI + BNC + S-Video video input, Audio with remote controller, open frame metal construction, Black color.

Document
Description
Download Link
file iconPMW6440-SP.pdf
Spec Sheet
file iconPMW6440-UM.pdf
User Manual
file iconMCS-UM.pdf
MCS User Manual
file iconTouch Screen Calibration Guide.pdf
Touch Screen Calibration Guide
  • PMW6440
    40 inch 1920 x 1080 widescreen LCD monitor
    VGA + DVI-D + HDMI + BNC video input
    Open frame metal construction
    VESA (M6, 8pcs) mount ready
    Single OSD menu control, option for MCS OSD
    110/240VAC power adapter, option for DC power
    Starting at:
    $1,545.00
PMW6440
$1,545.00

PRODUCT DESCRIPTION:
PMW6440 is a 40 inch 1920 x 1080 widescreen LED backlight industrial monitor is an active type LCD panel digital to digital which connects to the onboard conversion board. The monitor comes with a VGA + DVI-D + HDMI + BNC + S-Video video input and audio input on the back of the monitor for your industrial computer connection. option for TV tuner (NTSC / PAL) with analog input. The OSD function lets you adjust the LCD display for the best viewing angle. Option for MCS OSD menu controls up to 64 monitors. All the OSD buttons are located on the back of the LCD monitor. The monitor comes with a rugged metal open frame construction for panel or wall mount industrial display application. It comes standard with one 6' VGA cable and a 110/220VAC auto-switch power adapter. Option for 24V / 48V DC power supply. The open frame monitor comes with a front mounting bezel for panel or wall mount application or rear VESA (75mm) mounting holes for VESA mount application.
