NOTICE: PRODUCT EOL. REPLACEMENT PRODUCT IS PMW6156 15.6" Widescreen Open Frame LCD Monitor, 1920 x 1080, 250-nits brightness, VGA + HDMI + DVI

Panel mount monitor a 15.4 inch 1280 x 800 400-nit LED back light LCD panel with VGA video input port and -30 to 80 degree C wide range working temperature in a rugged metal open frame monitor enclosure.
Loading...
17

PM-S0170

RMW8241

RMW8241

PM-S0154

  • Open frame monitor with front mounting bracket
  • 15.4 inch 1280 x 800 LED backlight monitor
  • 400-nits high brightness LCD panel
  • -30 to 80 degree C wide range working temperature
  • VGA video input, Option for DVI or DVI + HDMI
  • Option for touch screen
  • Option for light or motion sensor
  • Option for 700 / 1000 nits high brightness panel
  • Panel/VESA (75mm) mount ready
  • External AC adapter, option for 24VDC power input
Availability: In stock
SKU
PM-S0154
Email
15.4 inch 1280 x 800 LED back light 400-nit LCD with VGA port & -30 to 80 degree C wide range working temperature, integrated into a metal open frame monitor enclosure, Option for touch screen, DVI or DVI + HDMI input, 700-nits / 1000-nits panel, motion or light sensor & 24VDC input.
Material
Heavy duty steel
LCD Panel
Size: 15.4 inch
Max Resolution: 1280 x 800
Brightness: 400 nits
Contrast Ratio (typ) : 400:1
Viewing Angle (H/V): 130° x 115°
Active Area (mm): 331.2 x 207.0
Colors: 262K
Signal Input: VGA
Backlight: LED
MTBF (hrs): 35,000
Option 700 / 1000 nits high brightness panel
Option digital signage (standalone), MP 480P/1080P
Option motion sensor or light sensor
Video input
VGA video input
Option for DVI or DVI + HDMI
Touch screen monitor (Option)
Resistive or Capacitive type touch screen, USB port
Protection (Option)
Protected glass (AR/AR with anti-vandal/AG)
Rear panel control
power on/off switch
OSD membrane switch
Audio System
2W speaker x 2
Mounting Type
Open frame monitor with front mounting bracket
VESA (75mm) mounting holes
Connectors
1 x VGA port (15 pin female D-Sub)
1 x PC Audio (stereo headphone jack)
1 x DC power plug
Power supply
External auto-sensing 90 to 260VAC, 50/ 60Hz power adapter
Option for 24VDC power supply
Weight
12.13lbs
Dimension
14.95"(W) x 10.94"(H) x 2.28"(D)
Environmental
Operating: -30°C to 80°C (22°F to 176°F)
Storage: -30°C to 80°C (22°F to 176°F)
Relative humidity: 10~90%, non-condensing
Certification
FCC, CE

PM-S0154:
15.4 inch 1280 x 800 400-nit high brightness LCD panel & open frame monitor, VGA video input, black color.
Option for touch screen, DVI / HDMI, high brightness panel, motion sensor, light sensor, digital signage (stand alone) & DC power supply.

Document
Description
Download Link
file iconPM-S0154-SP.pdf
Spec Sheet
  • PM-S0154
    15.4 inch 1280 x 800 panel mount monitor
    400-nits high brightness LCD panel
    Option for 700 and 1000-nits sunlight readable LCD panel
    Option for light and motion sensor
    15-pin VGA video input
    Option for DVI, SV+AV video input
    Option for touch screen
    External 110/220VAC power adapter
    Option for 24VDC power input
    Option for AR or AG glass protection
    Option for digital sigbage - stand alone
    Open frame monitor with front mounting bracket and VESA mounting holes
    Starting at:
PM-S0154

Presenting a 15.4 inch 1280 x 800 TFT LCD open frame monitor, PM-S0154’s wide range of operating temperature can function in harsh environments typically encountered in both industrial and commercial applications. The operating and storage temperatures can withstand in a wide range of -22°F to 176°F (-30°C to 80°C). The relative humidity tolerates at 10~90%, non-condensing.

The heavy-duty steel built protects the 15.4 inch monitor display of 1280 x 800, 400-nits brightness, 400:1 contrast ratio, 262K colors, LED backlight, and mean time of failure (MTBF) at 35,000 hours. The options for 700 or 1,000-nits high brightness, digital signage (stand alone) MP 480P or 1080P, motion sensor or light sensor, resistive or capacitive type touch screen with USB port, and protected glass (AR/AR with anti-vandal/AG) are all available to add on for extra features and protections.

The unit uses VGA video input with option for DVI or DVI and HDMI. The audio system is of 2W speaker x 2. The mounting type is of front mounting bracket and VESA mounting holes. The connectors include VGA port (15 pin female D-Sub), PC Audio (stereo headphone jack), and DC power plug. The power supply is of external auto-sensing 90 to 260VAC, 50/60Hz power adapter with option for 24VDC power supply.

New Ruggedized Wide Range Working Temperature Open Frame Panel Mount Monitor Series
Acnodes’ new professional LCD display series, the PM-S, features wide range working temperatures rated from -30 degrees to 80 degrees Celsius. These monitors can operate efficiently even in the most extreme conditions. The PM-S offers sizes ranging from 5.7” to 17” with optional built-in touch screens for interactive applications, ideal for outdoor kiosk, POS, and industrial automation.
