NOTICE: PRODUCT EOL. VISIT FANLESS INDUSTRIAL PANEL PCS - UL CERTIFIED FOR RELATED PRODUCTS.

Panel PC comes with 24 inch 1920 x 1080 full HD LCD panel and projected capacitive multi-touch screen, it powered by Core i7-3555LE 2.5GHz processor, it also comes with an IP65 rated flat front bezel, 9 ~ 36 VDC power input & -10 to 50 degree C wide range working temperature.
Loading...
10.1

PC9101

24

PMQ9240

PC5025

  • IP65 rated flat front bezel
  • 24 inch 1920 x 1080 full HD TFT LCD monitor
  • Projected capacitive multi-touch screen monitor
  • Core i7-3555LE 2.5GHz embedded computer
  • Ultra slim 2.13" in thickness
  • -10ºC to 50ºC wide range working temperature
  • 9~36V DC power input
Availability: In stock
SKU
PC5025
Email
Panel PC with 24 inch 1920 x 1080 full HD multi-touch screen and Core i7-3555LE 2.5GHz CPU with fan less cooling system, has an IP65 rated ultra slim flat front bezel and -10 to 50 degree C wide range working temperature.
Material
IP65 rated rugged enclosure
Ultra slim 2.13" in thickness
LCD panel
Size: 24”
Max. Resolution: 1920 x 1080
Brightness: 250nits
Contrast Ratio: 5000:1
Viewing Angel (H/V): 178° x 178°
Active Area(mm): 531.36(H) x 289.89(V)
Pixel Pitch (mm): 0.27675(H) x 0.27675(V)
Color: 16.7M
Option for 1000 nits high brightness panel
System
CPU: Core i7-3555LE 2.5GHz CPU
Memory: 4GB DDR3 SO-DIMM, Max. 8GB
Storage: 64GB mSATA SSD / 500GB SATAII HDD bay
Touch screen
Projected capacitive multi-touch screen monitor
Connectors
3 x COM, 2 for RS-232, 1 for RS-232/422/485
3 x USB, 2 for USB 2.0, 1 for USB 3.0
2 x Gigabit Ethernet ports (RJ-45)
1 x AC input
1 x HDMI output
Wireless Communication (Option)
802.11 b/g/n/ac + Bluetooth 4.0
Protection
Front IP65
Power supply
9~36V DC power input
Mounting (Option)
VESA or pipe mount
Color
Black
Dimension
22.83”(W) x 2.13"(D) x 14.69”(H)
Environmental
Operating: -10°C to 50°C (14°F to 122°F)
Storage: -30°C to 70°C (-22°F to 158°F)
Relative humidity: 10% to 95%, non-condensing
Vibration: 5Hz~500Hz/ 1Grms/ 3 Axis
Shock: 15G, 11ms duration

PC5025:
24 inch 1920 x 1080 full HD resolutions industrial Panel PC with IP65 rated flat front bezel, Core i7-3555LE 2.5GHz embedded computer, 4GB DDR3 memory, 64GB mSATA SDD or 500GB SATAII HDD, and projected capacitive multi-touch screen monitor.

NOTICE: PRODUCT EOL. VISIT FANLESS INDUSTRIAL PANEL PCS - UL CERTIFIED FOR RELATED PRODUCTS.

Document
Description
Download Link
file iconPC5025-SP.pdf
Spec Sheet
  • PC5025
    Panel PC
    Intel Core i7 3555LE 2.5GHz Dual Core CPU
    4GB DDR3 memory up to 8GB
    fanless cooling system
    24" 1920 x 1080P full HD display
    250-nits high brightness display
    projective capacitive Multi-touch screen
    1 x 2.5" SATA hard drive
    Built-in 802.11a/b/g/n/ac wireless LAN and bluetooth 4.0 moudule
    IP65 rated flat front bezel
    9 to 36 VDC power input
    75mm VESA mount ready
    Starting at:
PC5025

Ultra Slim Multi-Touch Panel PC Incorporates 24” 1080P Full HD LCD with Core i7-3555LE 2.5GHz Processor for the Industrial IOT Applications

A fanless designed intelligent multi-touch display unit. It is powered by Intel mobile 3rd generation Core i7-3555LE 2.5GHz processor with 25W low power consumption wattage and Dual Core with 4 threads performance, allowing end-users to experience maximum performance for everything they do. The PC5025 is equipped with a 24-inch flat touch panel LCD that supports 1920 x 1080 pixels full HD resolutions and incorporates projected capacitive technology with multiple point touch capacity. The fanless panel PC features a multitude of I/O connectivity built directly into its impressively small design such as; two Gigabit LAN, a USB 3.0, two USB 2.0, three Serial, Intel HD graphics and HDMI. The PC5025 also supports up to 8GB of DDR3 memory, Intel HD graphics 4000 and has optional built-in 802.11 b/g/n/ac + Bluetooth 4.0 wireless networking. With its rich I/O ports, this new solution makes it an ideal human-machine interface (HMI) platform for a variety of applications that are in need of peripheral connectivity, including information management, transportation, industrial automation and a variety of commercial and industrial applications.

It comes with an ultra-slim profile with only 2.13-inch depth and supports optional VESA or panel mounting. It enables easy installation in extreme and space-constricting environments. Acnodes has also kept in mind the industrial aspect of the Panel PC. The housing is made with a robust mechanical design, has an IP65 rated front metal bezel to protect against dust and water, and supports a wide operating temperature from 14°F to 122°F (-10°C to 50°C) and relative humidity of 10% to 95%. Moreover, the PC5025 boasts of anti-shock and vibration resistance. Its fanless design also ensures silent operation, improved reliability, and reduced maintenance.

PC5025:  24” Ultra Slim Multi-Touch Panel PC with projected capacitive touch screen, Core i7-3555LE 2.5GHz, IP65 rated front panel, configurations with 4GB DDR3 memory, 2 x Ethernet, 3 x Serial, 3 x USB, HDMI output, 9~36V DC power input.

24-inch touch Panel PC

References
What is an IP rating?
An IP rating refers to the degree of protection against water and dust provided by a computer's enclosure.
