PC5015

Overview:
PC5015 features a 15.6” 1366 x 768 LED backlight touch screen with IP65 rated rugged enclosure and 2M pixel camera. The PC is powered by the high-performance Celeron J1900 Quad Core 2GHz CPU with a 2GB 204-pin 1333MHz DDR3L SDRAM DIMM memory and 30GB m SATA SSD and 2.5” SATA HDD bay that offers immense storage capacity. The connectors include two COM ports, four USB, two Gigabit Ethernet ports, power switch, reset button, AT/ATX switch, line-out audio, and 3~30V lockable DC jack. The audio internal speaker is AMP 3W+3W. The wireless communication uses built-in IEEE 802. 11a/b/g/n/ac 2T2R module. The camera is 2M pixels with low light function. The power supply is 9~30V DC power input with an external AC power adapter. It has an option for RFID Mifare 13.56MHz card reader and magnetic stripe card reader.

With a wide range of operating temperatures, the PC can work in harsh environmental conditions. During operating, PC5015 can withstand an extended temperature range from -4°F to 122°F and be stored in temperatures from -4°F to140°F. The PC also has several options for mounts (wall, panel, stand, rack mount, VESA) that provide safe and easy installations. As an IP65 rated rugged enclosure, the PC is dustproof and waterproof. IP65 rated indicates the ability to protect against the ingress of dust and protection against the ingress of water projected by low-pressure water jets from any direction. These standards make the Panel PC ideal to work in harsh environments in both commercial and industrial use.

At 15.6”, the LCD panel has a maximum resolution of 1366 x 768, 300nits brightness, a contrast ratio of 700:1, 262K colors, and mean time between failures at 50000 hours. These features provide superior image quality and are long-lasting. The touch screen is a 5-wire resistive type with RS-232 controller. With this structure, the touch screen may still work properly even when the top layer is slightly scratched or damaged. The result is an accurate, durable, and reliable touch screen that offers a higher-touch life.

Key Features
- 15” 1366 x 768 LCD touch screen panel
- Celeron J1900 Quad-Core 2GHz
- IP65 rated flat front bezel
- 5-wire resistive type touch screen,
 option for projected capacitive multi-touch
- Wide range operating temperature (14°F to 122°F)
- 9~30V DC power input with external AC power
- AMP 3W + 3W internal speaker
- Built-in IEEE 802 wireless communication
- 2M pixels with low light function camera
