Panel PC comes with a 19 inch full IP67/69K rated anti-corrosion stainless steel touch panel, Celeron N2930 fanless CPU, 5-wire resistive type touch screen, and extended working temperature of -10°C to 55°C. Option for Core i5 5200U/Core i7 6600U CPU and DC power input.
Loading...
21.5

PCH8215

24

PCH8240

PCH8190

  • Full IP67/69K rated rugged stainless steel enclosure
  • 19 inch 1280 x 1024 LED backlight LCD monitor
  • 5-wire Resistive type touch screen
  • Intel Celeron N2930 1.83GHz processor
  • Option for Core i5 5200U / Core i7 6600U
  • 2 x USB + 1 LAN + 1 COM port
  • 110/240VAC power input, option for DC power input
  • Extended working temperature -10°C to 55°C
$1,981.00
Availability: In stock
SKU
PCH8190
Email
19" 1280 x 1024 fanless panel PC with Celeron N2930 processor, resistive type touch screen, full IP67/69K rated stainless steel chassis, and AC power input.
Material
SUS316 stainless steel
IP67/69K rated anti-corrosion stainless steel
LCD panel
Size: 19”
Max Resolution: 1280 x 1024
Brightness (cd/m²): 350
Contrast Ratio (typ.): 1000:1
Viewing Angle (H/V): -85~85 (H); -80~80 (V)
Colors: 16.7M, 6 bits
Option for high brightness / optical bonding
Touch screen
5-wire resistive type touch screen monitor
Option for projected capacitive touch screen
System
CPU: Celeron N2930 1.83GHz (std)
Option for Core i5 5200 / Core i7 6700
Memory: 1 x 4GB DDR3 SO-DIMM (Max.8GB)
Storage: 1 x 128GB SSD (Max.250GB)
Ethernet: 1 x Gigabit LAN
Option for WiFi and Bluetooth module
Connectors - C16 / IP Rated
Serial Ports: 1 x RS232 (IP67)
USB Ports: 2 x USB (IP67)
Ethernet: 1 x RJ45 GbE LAN (IP67)
Power: 1 x AC Input (IP66)
IP66 rated 6ft extended cables included for each I/O
Power Supply
110/240VAC power input
Power Consumption: 50W (typ)
Option for 9 to 36V DC power input
Weight
19.84 lb / 9 kg
Dimension
24.02”(W) x 8.67”(D) x 20.87”(H)
Mounting
VESA mount (100mm)
Option for panel mount with gasket
Environmental
Operating Temperature: -10°C to 55°C
Relative Humidity: 10% to 95%, non-condensing

PCH8190:
19 inch 1280 x 1024 industrial LCD, full IP67/69K rated stainless steel enclosure, Celeron N2930 1.83GHz CPU, resistive type touch screen, 2 x USB + 1 x LAN + 1 x COM, 6ft cables for each I/O, 110/240VAC power input.
Lead Time: 6 to 8 weeks

Document
Description
Download Link
file iconPCH8190-SP(V1-2).pdf
Spec Sheet
file iconPCH8XXX-UM(V1-2).pdf
User Manual
  • PCH8190
    Panel PC - Fanless Embedded Computer
    Full IP67/69K rated stainless steel enclosure
    Celeron N2930 1.83GHz CPU
    Option for Core i5 5200 / Core i7 6600U CPU
    4GB memory, up to 8GB
    1 x 128GB SSD, up to 250GB
    19 inch 1280 x 1024 350-nits LCD panel, option for high brightness
    Resistive type touch screen, option for Capacitive type touch screen
    110/240VAC power input, option for DC power input
    VESA mount ready
    Starting at:
    $1,981.00
PCH8190
$1,981.00
