RMW7215
21.5" FHD military-grade rackmount monitor with VGA + DVI input, -10°C to 60°C wide operating temperature, and MIL-STD-810G compliance in a 9U high rackmount enclosure.
Key Features
- ✓9U 21.5" rugged military rackmount LCD monitor
- ✓Supports 1920 x 1080 (FHD) pixel resolution
- ✓Designed for a standard 22" wide rack cabinet
- ✓VGA + DVI input, option for DP, HDMI, BNC, or Speaker-Audio
- ✓AR glass, option for ITO or Resistive / Capacitive touch screen
- ✓Front IP65-rated bezel for protection against dust and water
- ✓MIL-STD-810G compliance for vibration, shock, humidity
- ✓Extended working temperature from -10°C to 60°C
- ✓DC power input with external AC power adapter
The RMW7215 is a 21.5" Full HD rugged military display supporting 1920 x 1080 display resolution and VGA + DVI input in a 9U high rackmount enclosure. Designed for harsh environments and military applications, it features an IP65-rated front bezel, a wide operating temperature range from -10°C to 60°C, and MIL-STD-810G compliance for vibration, shock, and humidity. The RMW7215 features a modularized design that provides flexible configurations including touch screen technology, ITO glass protection, 1000-nits high brightness display, light sensor, additional video inputs, and D38999 connector.
| Material | Heavy-duty steel |
| LCD Panel | Size: 21.5 inch Resolution: 1920 x 1080 @ 60Hz Brightness (cd/m²): 250-nits, option for 1000-nits high brightness Contrast Ratio (typ.): 1000:1 Active Area: 476.64(H) x 268.11(V) Pixel Pitch (mm): 0.248(H) x 0.248(V) Viewing Angle: -85 ~ 85 (H); -80 ~ 80 (V) Max Colors: 16.7M (8 bits + FRC) |
| LCD Protection / Touch Screen (Option) | AR protective glass (standard) Option for ITO glass with no touch Option for Resistive or Capacitive touch screen with no AR or ITO glass |
| Light Sensor (Option) | Dimmer light sensor |
| Optical Bonding (Option) | Optical bonding |
| Video Input | VGA + DVI video input Option for DP, HDMI, BNC, or Speaker-Audio input |
| Front Panel Controls | Power on/off button 7-key OSD buttons |
| OSD Menu Control | OSD control for contrast, color, position, auto-adjustment, factory settings, PIP between signal inputs |
| Mounting | 9U high rackmount monitor for a standard 22 inch wide rack cabinet |
| Connectors | 1 x VGA (D-sub 15-pin), Sync on green (SOG) supported 1 x DVI input 1 x DP input (optional) 1 x HDMI input (optional) 1 x BNC input (optional) 1 x Speaker-Audio input (optional) 1 x 3-pin D38999 power connector w/ power adapter |
| Power Supply | DC power with external AC power adapter Power Consumption: 40W typical, normal operation Option for D38999 9 to 36V DC power input or D38999 AC power input Option for MIL-STD-461E power EMI filter |
| Environmental | Operating Temperature: -10°C to 60°C Option for -20°C to 60°C wide operating temperature Storage Temperature: -30°C to 70°C Operating Humidity: 5% to 95%, non-condensing Vibration: MIL-STD-810G Method 514.6C-3 compliant Shock: MIL-STD-810G Method 516.6 compliant Humidity: MIL-STD-810G Method 507.5-7 compliant IP Level: Front IP65 rated bezel |
| Compliance | FCC, CE, RoHS |
| Weight | 31-33 lb / 14-15 kg |
| Dimension | 20.47"(W) x 2.38"(D) x 14.17"(H) |
