RMW7195
19 inch 1440 x 900 military-grade LCD monitor with VGA + DVI video input, IP65 rated aluminum front bezel, MIL-STD-810G compliance, and an 8U high rakcmount enclosure.
Key Features
- ✓8U 19" rugged military rackmount LCD monitor
- ✓Supports 1440 x 900 pixel resolution
- ✓250-nit brightness, option for 1000-nit high brightness
- ✓VGA + DVI video input, option for DP, HDMI, or BNC input
- ✓Option for dimming light sensor and optical bond
- ✓IP65 rated anodized aluminum front bezel
- ✓MIL-STD-810G compliance for vibration and shock
- ✓Extending working temperature of -10°C to 55°C
- ✓DC power input with external AC power adapter
The RMW7195 is an 8U high 19" rugged military rackmount LCD monitor with an IP65-rated anodized aluminum front bezel in an 8U high rackmount enclosure. The display supports 1440 x 900 widescreen resolution, 1000:1 contrast ratio, 160° x 170° viewing angle, and an active area of 408.24H x 255.15V mm. Designed for harsh environments and military applications, the RMW7195 features an AR protection glass, -10°C to 55°C extended working temperature, and MIL-STD-810G compliance for vibration, shock, and humidity.
| Construction | IP65 rated anodized aluminum front bezel |
| LCD Panel | Size: 19 inch Max Resolution: 1440 x 900 Brightness (cd/m²): 250, option for 1000-nit Contrast Ratio (typ.) : 1000:1 Viewing Angle (H/V): 160° x 170° Active Area (mm): 408.24H x 255.15V Pixel Pitch (mm): 0.2835H x 0.2835V Colors: 16.7M, 6-bit + FRC Backlight: LED |
| LCD Protection | AR protective glass Option for ITO glass |
| Video Input | VGA + DVI video input Option for DP, HDMI, BNC, or Speaker-Audio input |
| Front OSD Buttons | OSD Control: 1 x Power, 1 x Enter (Menu), 1 x Space, 1 x Up, 1 x Down for OSD control Keyboard FN Keys: ESC, F1, F2, 1~5 mapping to keyboard (programmable to other keys) LED Indicators: 1 x Power On/Off, 1 x Sleep/Stand by |
| Light Sensor (Option) | Dimmer light sensor |
| Optical Bonding (Option) | Optical bonding |
| Connectors | 1 x VGA + 1 x DVI 1 x DP (option) 1 x HDMI (option) 1 x BNC (option) 1 x 3-pin D38999 power connector |
| Power Supply | DC power with external AC power adapter Power Consumption: 33W (typical) Power Management: VEDA DPMS compliant Option for D38999 9 to 36V DC power input or D38999 AC power input Option for MIL-STD-461E power EMI filter |
| Environmental | Operating Temperature: -10°C to 55°C Storage Temperature: -30°C to 70°C Operating Humidity: 5% to 95%, non-condensing Vibration: MIL-STD-810G Method 514.6C-3 compliant Shock: MIL-STD-810G Method 516.6 compliant Humidity: MIL-STD-810G Method 507.5-7 compliant |
| IP Level | IP65 in front, IP54 in rear |
| Gross Weight | 22.05 lb / 10 kg |
| Dimension | 18.90"(W) x 4.72"(D) x 12.99"(H) |
This product does not have configurable options.
