RMW6170
17.3" 1920 x 1080P Full HD rackmount LCD monitor with VGA + HDMI video input and 100/240VAC power input in an 8U high rackmount enclosure.
Key Features
- ✓6U 17.3" FHD rackmount LCD monitor
- ✓Supports 1920 x 1080 native resolution
- ✓Front OSD (on-screen display) function
- ✓VGA + HDMI video input
- ✓Option for DVI-D, DP, Audio, Speaker, or 3G/HD/SD-SDI input
- ✓Option for Resistive or Projected Capacitive touch screen - USB
- ✓Auto-sensing 100 to 240VAC, 50 / 60Hz power input
- ✓Option for 12V / 24V / 48V / 125V DC power input
The RMW6170 is a high-quality 6U 17.3" FHD rackmount LCD monitor designed to meet your display needs in any professional setting. Featuring a native resolution of 1920 x 1080, this monitor delivers crystal-clear images that are sure to impress. The front OSD (on-screen display) function allows you to easily adjust the settings to your preference, while the VGA + HDMI video input ensures compatibility with a wide range of devices. Additionally, the RMW6170 also offers the option for DVI-D, DP, Audio, Speaker, or 3G/HD/SD-SDI input, providing you with even more flexibility and versatility.
| Construction | Heavy-duty steel |
| LCD panel | Size: 17.3 inch Max Resolution: 1920 x 1080 Brightness (cd/m²): 300 Contrast Ratio (typ.) : 1000:1 Colors: 16.7 M, 8-bit Viewing Angle (H/V): 178° x 178° Response Time (ms): 25 Dot Pitch (mm): 0.1989 Display Area (mm): 381.888H x 214.812V Surface Treatment: Anti-glare, Hard-coating Surface Hardness: 3H Backlight: LED MTBF (hrs): 15,000 |
| Video Input | Standard: VGA + HDMI video input Option: DVI-D, DP, Audio, Speaker, or 3G/HD/SD-SDI input |
| Touch screen (Option) | Resistive 1-pt touch screen - USB port Projected Capacitive 1-pt / 10-pt touch screen - USB |
| Front panel control | Power on/off switch OSD membrane switch |
| Connector | 1 x VGA + 1 x HDMI |
| Power Supply | Input: Auto-sensing 100 to 240VAC, 50/ 60Hz Consumption: Max. 14 Watt, Standby 2 Watt Option for 12V / 24V / 48V / 125V DC power input |
| Mounting | 6U high rackmount monitor for a standard 19" wide rackmount cabinet |
| Color | Black front panel (RAL 9005) |
| Environmental | Operating Temperature: 0°C to 55°C Storage Temperature: -20°C to 60°C Relative Humidity: 5~90%, non-condensing Altitude (Operating / Non-Operating): 16,000 ft / 40,000 ft Shock: 10G acceleration (11 ms duration) Vibration: 10~300Hz 0.5G RMS random vibration |
| Compliance | CE, FCC, RoHS, TAA |
| Weight | 9.8 lb / 4.5 kg |
| Dimension | Product: 18.9"(W) x 1.9"(D) x 10.5"(H) Packing: 20.8"(W) x 4.9"(D) x 17.8"(H) |
