RMC8405
4U rack PC with 9th Gen. Intel Core i CPU, single-board computer (SBC) with PICMG 1.3 13-slot backplane, 2 x 5.25" external drive bays, and a 16.1" short-depth rack chassis.
Key Features
- ✓4U high rackmount computer
- ✓16.1" short-depth steel rackmount chassis
- ✓9th generation Intel Core i3 / i5 / i9 processors
- ✓Single board computer PICMG 1.3
- ✓13 x PCI / PCIe / SBC slot backplane
- ✓4GB memory (up to 32GB) & SATA hard drive
- ✓2 x 5.25" external drive bays
- ✓Front single door with two thumbscrews
- ✓400W ATX power supply, option for 500W or 650W ATX P/S
The RMC8405 is a 4U rackmount computer powered by the 9th Generation Intel Core i processors with an industrial-grade single board computer (SBC), PICMG 1.3 13-slot backplane, and two 5.25" external drive bays. The front panel features a single front door with two thumbscrews and a removable and washable air filter. Furthermore, this 4U system comes with a flexible hold-down bar design to protect the plug-in cards from vibration. Utilizing a full-size single-board computer with the 9th generation Intel Core i processor, this 4U rackmount PC delivers high-performing computing powers for your industrial requirements and business environments.
| Construction | Heavy-duty cold-rolled steel Inside: Zinc-plated with bright chromate Outside: Texture-coated |
| Standard ATX M/B | Size: Full-size single board computer Processor: 9th generation Intel Core i processor Memory: 2 x memory sockets (up to 32GB memory) Dual 10/100/1000BT Ethernet LAN ports 1 x VGA (onboard) & 1 x DVI (occupies one slot) port 6 x SATA connectors 2 x RS-232, 4 x USB ports |
| Drive Capacity | 2 x 5.25” open drive bays |
| Backplane | 13 Slot Backplane PICMG 1.3 A: PCIe x1 (3), PCIe x16 (1), PCI (8) B: PCIe x16(1), PCIe x16(2, x1 signal), PCIe x4(5, x1 signal), PCI(4) |
| Front Panel Controls | Power on/off switch System reset button |
| Front Door | Single door with two thumbscrews |
| Cooling Fan | 1 x 90mm (51cfm) ball bearing fan |
| Air Filter | Removable and washable air filter |
| Power Supply | 400W auto-switch ATX power supply Option for 500W or 650W ATX power supply |
| Slide Rail (Option) | Option for 20" to 26" adjustable slide rail |
| Color | Black |
| Environmental | Operating Temperature: 0°C to 50°C Humidity: 5% ~ 95%, non-condensing |
| Weight | 40 lb / 18.14 kg |
| Dimension | 19"(W) x 7.0"(H) x 16.1"(D) |
This product does not have configurable options.
