RMC5285
2U rackmount PC with standard ATX M/B, 13/14th Intel Core i CPU, 4 x 2.5" external hot-swap drive bays, up to 5 x PCIe slots, and a 2U high 17.7" short-depth rack chassis.
Key Features
- ✓2U high rackmount computer
- ✓17.7" short-depth design for space critical applications
- ✓13/14th Gen Alderlake Intel Core processors
- ✓Standard ATX motherboard
- ✓Up to 5 x PCIe expansion slots
- ✓Supports up to 4 x 2.5" external hot-swap drive bays
- ✓Supports GPU card with 2U riser card
- ✓4 x easy swap fans for superior cooling abilities
- ✓800W 1+1 redundant PSU 80+ Platinum
The RMC5285 is a 2U rackmount computer designed with adjustable front and rear panels that provide adjustability, compatibility, and accessibility for your system. This 2U system supports a standard ATX motherboard with 13/14th Gen Intel Core processors, 4 x 2.5" external hot-swap drive bays, 4 x easy swap fans for superior cooling, a GPU card with 2U riser card, and a redundant PSU 80+ Platinum power supply. The RMC5285 is designed for edge computing appliances and industrial applications.
| Construction | Heavy-duty preplated SPGC cold-rolled steel EIA-RS310D industry standard |
| System Board | Size: Standard ATX motherboard RMC5285-B: Low-profile card at rear Processor: 13/14th Gen Intel Core processors Memory: 4 x DIMM memory socket (up to 32GB memory) On-board Video, LAN, Audio SATA connector USB ports |
| Drive Bays | 4 x 2.5" external hot-swap drive bays |
| Backplanes | 2 pcs dual port SATA BP to support 4 x SATA |
| Expansion Slot | RMC5285-B: 1 x PCIe 5.0 x16 + 1 x PCIe 3.0 x4 + 2 x PCIe 3.0 x1 + 1 x PCIe 3.0 x16 |
| Front Panel Controls | System power on/off switch System reset button 2 x USB ports |
| LED Indicators | Power status LAN activity Drive activity |
| Cooling Fan | 4 x 60x38mm easy swap fans |
| Power Supply | 800W 1+1 redundant PSU 80+ Platinum |
| Mounting | Option for 20" slide rail |
| Color | Black |
| Environmental | Operating Temperature: 0°C to 50°C (32°F to 122°F) Humidity: 5%~95%, non-condensing |
| Expansion Slot Size | RMC5285-B: Standard low profile size |
| Gross Weight | 28.5 lb / 13 kg (w/ PSU; w/o Rail) |
| Dimension | 17.2"(W) x 17.7"(D) x 3.5"(H) |
This product does not have configurable options.
