RMC4402
4U rackmount GPU workstation supporting a standard ATX M/B, 2 xM.2 internal drive bays, RTX 5070 12GB graphics card, and a 4U 18.43" depth rack chassis.
Key Features
- ✓4U rackmount GPU workstation
- ✓Standard ATX motherboard
- ✓Intel Ultra 2 or AMD Ryzen processors
- ✓16GB DDR5 memory (up to 32GB) & 500GB NVMe SSD
- ✓Designed for RTX 4070 12GB graphics card
- ✓Supports 1 x 360mm AIO liquid CPU cooler & 2 x 80mm rear cooling fans
- ✓Supports sliding rail mounting holes for quick rail installation
- ✓Includes 1 x front USB Type-C port & 2 x front USB 3.0 ports
- ✓2 x M.2 internal drive bays
- ✓1000W single ATX power supply
The RMC4402 is a powerful and versatile 4U rackmount GPU workstation designed to meet the demands of compute-intensive applications. The workstation comes equipped with a standard ATX motherboard providing compatibility with a broad range of hardware components. It features an Intel Ultra 2 or AMD Ryzen processor, delivering exceptional processing power and performance. Designed specifically for RTX 5070 12GB graphic cards, this workstation is ideal for professionals who need to handle demanding tasks, such as data visualization and rendering. It also supports a 240mm AIO liquid CPU cooler and 2 x 80mm rear cooling fans, ensuring optimal system cooling for stable operation. With its advanced hardware and flexible design, the RMC4402 is an ideal choice for a wide range of applications, from scientific research to graphics design.
| Construction | Heavy duty steel |
| System | Standard ATX Motherboard: ASUS standard ATX M/B Processor: RMC4402-A: AMD Ryzen processors RMC4402-B: Intel Ultra 2 processors Memory: 16GB DDR5, up to 64GB Storage: 500GB M.2 SSD |
| Drive Bays | 2 x M.2 internal drive bays |
| Expansion Slots | 1 x PCI Express 4.0 x16 (Support may vary by CPU) 1 x PCI Express 3.0 x16 2 x PCIe 3.0 x 1 |
| Graphics Card | Supports RTX 5070 12GB graphics card |
| Front Panel Control | 1 x USB Type C port 2 x USB 3.0 ports 1 x Power Status LED Indicator 1 x HDD Activity LED Indicator 2 x LAN Activity LED Indicators |
| Security | Front drive panel door with keylock |
| Cooling Fans | 2 x 80mm rear cooling fans |
| Liquid CPU Cooler (Option) | Option for 1 x 240mm AIO liquid CPU cooler or 1 x 360mm AIO liquid CPU cooler |
| Limitation of CPU Cooler | Height w/ expansion card retainer: 137mm Height w/o expansion card retainer: 148mm |
| Power Supply | 1000W single ATX power supply Option for 1200W single ATX P/S or 800W mini redundant P/S |
| Color | Black |
| Environmental | Operating Temperature: 0°C to 55°C Humidity: 5~95%, non-condensing |
| Operating System | Option for Windows 11 Professional 64-Bit (TPM 2.0 Requited) OS |
| Compliance | CE, FCC, RoHS |
| Expansion Card Size | Length: 424mm (without installing front fans and radiators) Height w/ expansion slot retainer: 113mm Height w/o expansion card retainer: 154mm |
| Weight | 20.23 lb / 9.2 kg |
| Dimension | 17.32”(W) x 6.93”(H) x 18.43”(D) |
This product does not have configurable options.
