RM6190N
19" 1280 x 1024 rackmount LCD monitor with VGA + HDMI (no speaker) video input, front OSD membrane controls, and a 100/240VAC power input in an 8U high rackmount enclosure.
Key Features
- ✓8U 19" rackmount LCD monitor
- ✓Supports 1280 x 1024 native resolution
- ✓Front OSD (on-screen display) function
- ✓VGA + HDMI (no speaker) video input
- ✓Option for DVI-D, BNC, Audio, Speaker, or 3G/HD/SD-SDI input
- ✓Option for Resistive or Projected Capacitive touch screen - USB
- ✓Option for front IP65-rated bezel protection
- ✓Auto-sensing 100 to 240VAC, 50 / 60Hz power input
- ✓Option for 12V / 24V / 48V / 125V DC power input
The RM6190N, our 8U 19-inch rackmount LCD monitor designed for industrial and commercial applications.
Key features include:
- High-Quality Visuals: Supports a native resolution of 1280 x 1024.
- Flexible Connectivity: Standard VGA and HDMI (no speaker) inputs, with options for DVI-D, BNC, Audio, Speaker, or 3G/HD/SD-SDI.
- Touch Screen Options: Available with Resistive or Projected Capacitive (USB) touch screens.
- Global Compatibility: Auto-sensing 100 to 240VAC, 50/60Hz power input.
The RM6190N provides a reliable and robust solution for various rackmount needs. Please let me know if you require any additional information or a formal quote.
| Construction | Heavy-duty steel Option for IP65 rated front bezel protection |
| LCD Monitor | Size: 19 inch Max Resolution: 1280 x 1024 Brightness (cd/m²): 250 Contrast Ratio (typ.) : 1000:1 Colors: 16.7M Viewing Angle (H/V): 170° x 160° Response Time (ms): 5 Dot Pitch (mm): 0.294 Display Area (mm): 376.32H x 270.33V Surface Treatment: Haze 25%, Hard-coating Surface Hardness: 3H Backlight: LED MTBF (hrs): 30,000 |
| Video Input | Standard: VGA + HDMI video input Option: DVI-D, BNC, Audio, Speaker, or 3G/HD/SD-SDI input |
| Touch Screen (Option) | Resistive 1-pt touch screen - USB port Projected Capacitive 1-pt / 10pt touch screen- USB port *Dimension will be changed to 9U if Projected Capacitive touch screen is selected |
| Connector | 1 x VGA + 1 x HDMI (no speaker) |
| Front Panel Control | Power on/off switch OSD membrane switch |
| Power Supply | Input: Auto-sensing 100 to 240VAC, 50/60Hz Consumption: Max. 22 Watt, Standby 2 Watt Option for 12V / 24V / 48V / 125V DC power input |
| Mounting | 8U high rackmount monitor for a standard 19" wide rackmount cabinet |
| Casing Color | Black front panel (RAL 9005) |
| Environmental | Operating Temperature: 0°C to 55°C Storage Temperature: -20°C to 60°C Relative Humidity: 5~90%, non-condensing Altitude (Operating / Non-Operating): 16,000 ft / 40,000 ft Shock: 10G acceleration (11 ms duration) Vibration: 10~300Hz 0.5G RMS random vibration |
| Compliance | CE, FCC, RoHS, TAA |
| Weight | 12.5 lb / 5.7 kg |
| Dimension | Product: 18.9"(W) x 2.1"(D) x 14"(H) Packing: 21.2"(W) x 5.1"(D) x 20.8"(H) |
