PM9107-ML
7 inch 800 x 640 rugged LCD monitor with an aluminum enclosure, anti-corrosion chromate coating, DVI-I video input, and 9 ~ 36V DC power input (D38999 connector).
Key Features
- ✓7 inch 800 x 480 industrial LCD monitor
- ✓350-nit high brightness LCD panel
- ✓DVI-I video input - D38999 connector
- ✓Supports portrait and horizontal display mode
- ✓AR glass protection with EMI filter
- ✓MIL-STD-810G & MIL-STD-461F certification
- ✓Aluminum enclosure with anti-corrosion chromate coating
- ✓Panel mount with EMI Gasket & VESA mount ready
- ✓9 ~ 36V DC power input - D38999 connector
Panel mount monitor comes with a 7 inch 800 x 480 LCD, aluminum enclosure with anti-corrosion chromate coating, D38999 connector, anti-EMI AR glass, and MIL-STD-810G/461F standards for military display applications.
| Material | Aluminum enclosure with anti-corrosion chromate coating |
| LCD panel | Size: 7 inch (16:9) Max Resolution: 800 x 480 Brightness (cd/m²): 350 Contrast Ratio (typ.) : 400:1 Viewing Angle (H/V): 140° x 110° Active Area (mm): 153.6 (V) x 90 (H) Colors: 262K MTBF (hrs): 35,000 Portrait Mode: Horizontal and Portrait |
| LCD Protection | AR glass with EMI Filter |
| Video Input | DVI-I video input |
| OSD Menu | 5-key membrane OSD menu to adjust display brightness - Rear Side |
| Connectors | 1 x DVI-I port (D38999 connector) 1 x DC power port (D38999 connector) |
| Mounting Type | Panel mount with EMI gasket VESA (75 x 75mm) mounting holes |
| Power Supply | 9 ~ 36V DC power input Power Consumption: 15W |
| Environmental | Operating Temperature: 0°C to 55°C (32°F to 131°F) Storage Temperature: -30°C to 70°C (-22°F to 158°F) Relative Humidity: 10~95 0%, non-condensing Vibration: MIL-STD-810G Method 514.6C-3 Shock: MIL-STD-810G Method 516.6 EMI: MIL-STD-461F (RE101, RE102, CE101, CS102, CS114, CS116, RS101, RS103) |
| Weight | 5.67 lb / 2.57 kg |
| Dimension | 7.67"(W) x 6.26"(H) x 2.68"(D) |
This product does not have configurable options.
