APM6084
Panel mount monitor with 8.4-inch 800 x 600 industrial LED backlight LCD, VGA, metal front bezel, DC power input & wall / VESA mount ready. Option for resistive or capacitive type touch screen & DVI / HDMI inputs.
Key Features
- ✓Metal front bezel
- ✓8.4 inch 800 x 600 industrial monitor
- ✓VGA video input
- ✓Option for DVI / HDMI inputs
- ✓Option for resistive or capacitive type touch screen monitor
- ✓Wall mount/ VESA mount ready
- ✓12V DC power input
8.4" panel mount monitor a 800 x 600 industrial LCD panel with metal front bezel, VGA input, wall or VESA mount ready & 12V DC power input . Option for resistive or capacitive type touch screen & DVI / HDMI inputs.
| Material | Metal front bezel |
| LCD Panel | Size: 8.4 inch Resolution: 800 x 600 Brightness: 350 Contrast Ratio (typ): 600:1 Viewing Angle (H/V): 160° x 140° Active Area (mm): 170.4 x 127.8 Pixel Pitch (mm): 0.213 x 0.213 Color: 262K Signal Input: VGA Backlight: LED MTBF (hrs): 35,000 |
| Video input | VGA video input Option for DVI/HDMI |
| Audio System | 2W Speaker x 2 |
| Connector | 1 x VGA 1 x PC Audio (Stereo Headphone Jack) 1 x DC Power Plug |
| Touch screen monitor (Option) | Resistive or Capacitive type touch screen monitor USB port |
| Glass Surface | Black anti-glare, low reflection coating |
| OSD | Auto Calibration, Back light adjustment, Plug&Play (VESA DDC/CI, DDC 2B), Multi-languages |
| Mounting Type | Wall mount or VESA mount |
| Power supply | 12V DC power input Consumption: 8.68 Watt, Power Saving < 2 Watt |
| Environmental | Operating: 0°C to 50°C (32°F to 122°F) Storage: -20°C to 60°C (-4°F to 140°F) Relative humidity: 10~90%, non-condensing |
| Certification | FCC, CE |
| Weight | 7.72lbs |
